Tower crane sany 6013-8 2020 used

Comprehensive Features

High Performance:

The rated lifting capacity at the end of the long boom is 1.3 tons. The maximum lifting moment reaches 1320 kN・m. The maximum boom length is 60 meters. Seven combinations of boom lengths from 30 to 60 meters can be realized, which can meet different construction requirements.

For the segmented market of small precast concrete element lifting, the lifting capacity of the boom length of 30 to 40 meters is improved. The maximum lifting capacity at the end of the 35-meter boom is 3.25 tons, which meets the lifting requirements of small precast concrete elements.

Adopting new powder coating technology, which improves the surface finish and wear resistance by more than 30%.

High Safety: With ten tower crane safety protection and management technologies, it achieves three-dimensional protection and guarantees construction safety.

High intelligence:

Working conditions display technology can display twelve working conditions information, the monitoring is clear at a glance.

Intelligent fault diagnosis function can diagnose and alarm more than twenty alarms.

Adopting high-quality display integration, integrating 7-inch high-quality color display, controller and communication control module, convenient installation.

Low-voltage integration module is the first in the industry, integrating power supply, circuit breaker, relay, eddy current and other modules, at the same time optimizing the wiring harness, simplifying the wiring and reducing the volume of the control cabinet.

High use experience:

Good controllability. The three main mechanisms adopt full frequency control. Five-stage connection console control, good micro-motion, the speed varies according to the load, high efficiency of slow positioning in lifting micro-motion.

With one-click to place function, can one-click control the lifting, rotating and lowering to the designated place.

Humanized design, such as installing oil-proof gutter to prevent the oil from the rope from falling onto the ladder; adopting quick-assembly structure, shortening the installation and dismantling time; installing rotating tower structure, wider visibility for the operator; large space in the driver's cabin, 10% larger than its competitors, and also equipped with air conditioning, fan, cup holder, etc. as standard, greatly improving the comfort.
